SCM200ASLT

Overview

  • 25mm soft dome tweeter
  • Twin, full spec “SL” 12″/314mm bass drivers
  • ATC 75mm “Super Dome” mid driver
  • Rack-mount ATC 4-way grounded source 850W P4 amplifier
  • Any veneer or painted finish
  • 6 year warranty

Specification

Drivers: HF 25mm, Mid 75mm, LF 2 x 375mm
Amplitude Linearity (±2dB): 60Hz-12kHz
Cut-off Frequencies (-6dB, free-standing): 32Hz, 20Khz
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 118dB
Crossover Frequencies: 380Hz, 3.5kHz
Input Connectors: Male XLR
Input Sensitivity: 2V
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 275+275W, Mid 200W, High 100W
Filters: Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection
Dimensions (HxWxD): 1586 x 398 x 535mm/62.4″x15.7″21.1″
