SCM300ASLT

Overview

  • 25mm soft dome tweeter
  • Twin full spec “SL” 15″/375mm bass drivers
  • ATC 75mm “Super Dome” mid driver
  • Rack-mount ATC 4 way grounded source 850W P4 amplifier
  • Any veneer or painted finish
  • 6 year warranty

Specification

Drivers: HF 25mm, Mid 75mm, LF 2 x 375mm
Amplitude Linearity (±2dB): 50Hz-12kHz
Cut-off Frequencies (-6dB, free-standing): 20Kh z
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 121dB
Crossover Frequencies: 380Hz, 3.5kHz
Input Connectors: Male XLR
Input Sensitivity: 2V
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 275+275W, Mid 200W, High 100W
Filters: Even Order Critically Damped
Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection
LF EQ: +6dB @ 40Hz
Dimensions (HxWxD): 1500 x 500 x 580mm (59.1″ x 19.7″ x 22.8″)
Weight: 96kg/211.6lbs
